Tuubada caagga ah ee rio



Ku saabsan sheyga

Laydh ku saleysan cabirkii foolanayd, dhumuc xidhnaa, xagal, radius, iyo fuugxiga xoojinta si loo buuxiyo shuruudaha arjiga gaarka ah.

Astaamo kala duwan

o Way fududahay in la rakibo marka loo eego jajabinta birta ee birta ah ee birta leh.

o Waxaa lagu xardhay wejiga 'rio latex webs' oo isku-darka ah, oo ay ikhtiyaar u leeyihiin inay dib u xoojiso aagagga u nugul.

o awood u leh cabirka goobta iyo habeynta si loogu habeeyo shuruudaha gaarka ah.

（China Flange National Standard: GB/T 9119-2010）
No.	Hose Specifications	Product No.	N.D. φD	L1=L2	R		Liner Thickness
1	DN100PN16R1.5D-α	R-XW-G-1.5D-α-2004	102	100	1.5D	153	6
2	DN125PN16R1.5D-α	R-XW-G-1.5D-α-2005	127	100	1.5D	191	6
3	DN150PN16R1.5D-α	R-XW-G-1.5D-α-2006	152	100	1.5D	228	6
4	DN200PN16R1.5D-α	R-XW-G-1.5D-α-2007	203	100	1.5D	305	6
5	DN250PN16R1.5D-α	R-XW-G-1.5D-α-2008	254	100	1.5D	381	6
6	DN300PN16R1.5D-α	R-XW-G-1.5D-α-2009	299	100	1.5D	449	6
7	DN350PN16R1.5D-α	R-XW-G-1.5D-α-2010	351	100	1.5D	527	10
8	DN400PN16R1.5D-α	R-XW-G-1.5D-α-2011	402	100	1.5D	603	10
9	DN450PN16R1.5D-α	R-XW-G-1.5D-α-2012	450	100	1.5D	675	15
10	DN500PN16R1.5D-α	R-XW-G-1.5D-α-2013	480	100	1.5D	720	15
11	DN600PN16R1.5D-α	R-XW-G-1.5D-α-2014	580	100	1.5D	870	15
12	DN700PN16R1.5D-α	R-XW-G-1.5D-α-2015	630	100	1.5D	945	15
13	DN800PN16R1.5D-α	R-XW-G-1.5D-α-2016	780	100	1.5D	1170	15

1	DN100PN16R3D-α	R-XW-G-3D-α-2004	102	100	3D	306	6
2	DN125PN16R3D-α	R-XW-G-3D-α-2005	127	100	3D	381	6
3	DN150PN16R3D-α	R-XW-G-3D-α-2006	152	100	3D	456	6
4	DN200PN16R3D-α	R-XW-G-3D-α-2007	203	100	3D	609	6
5	DN250PN16R3D-α	R-XW-G-3D-α-2008	254	100	3D	762	6
6	DN300PN16R3D-α	R-XW-G-3D-α-2009	299	100	3D	897	6
7	DN350PN16R3D-α	R-XW-G-3D-α-2010	351	100	3D	1053	10
8	DN400PN16R3D-α	R-XW-G-3D-α-2011	402	100	3D	1206	10
9	DN450PN16R3D-α	R-XW-G-3D-α-2012	450	100	3D	1350	15
10	DN500PN16R3D-α	R-XW-G-3D-α-2013	480	100	3D	1440	15
11	DN600PN16R3D-α	R-XW-G-3D-α-2014	580	100	3D	1740	15
12	DN700PN16R3D-α	R-XW-G-3D-α-2015	630	100	3D	1890	15
13	DN800PN16R3D-α	R-XW-G-3D-α-2016	780	100	3D	2340	15

1	DN100PN16R5D-α	R-XW-G-5D-α-2004	102	100	5D	510	6
2	DN125PN16R5D-α	R-XW-G-5D-α-2005	127	100	5D	635	6
3	DN150PN16R5D-α	R-XW-G-5D-α-2006	152	100	5D	760	6
4	DN200PN16R5D-α	R-XW-G-5D-α-2007	203	100	5D	1015	6
5	DN250PN16R5D-α	R-XW-G-5D-α-2008	254	100	5D	1270	6
6	DN300PN16R5D-α	R-XW-G-5D-α-2009	299	100	5D	1495	6
7	DN350PN16R5D-α	R-XW-G-5D-α-2010	351	100	5D	1755	10
8	DN400PN16R5D-α	R-XW-G-5D-α-2011	402	100	5D	2010	10
9	DN450PN16R5D-α	R-XW-G-5D-α-2012	450	100	5D	2250	15
10	DN500PN16R5D-α	R-XW-G-5D-α-2013	480	100	5D	2400	15
11	DN600PN16R5D-α	R-XW-G-5D-α-2014	580	100	5D	2900	15
12	DN700PN16R5D-α	R-XW-G-5D-α-2015	630	100	5D	3150	15
13	DN800PN16R5D-α	R-XW-G-5D-α-2016	780	100	5D	3900	15

Waqti dheer oo waara oo gashan tuubada caagga ah ee caagga ah
